Reproduction Quality very high-resolution scanned copy on CD-ROM
of the (RARE) SERVICE TRAINING CLASS MANUAL for the
Very detailed ("Push this button , now push that button") step by step discussion on the various 7704A circuits and how to troubleshoot them. The discussion on troubleshooting the power supply alone is worth the price of this CD.
* DETAILED CIRCUIT DESCRIPTION AND TROUBLESHOOTING INFO FOR:
* LV POWER SUPPLY / REGULATOR
* HIGH RESOLUTIONS SCANS (300-600DPI) OF ORIGINAL TEKTRONIX MANUAL
* 131-PAGES IN 4-MB PDF FORMAT FILE
SATISFACTION GUARANTEED OR YOUR MONEY BACK !
