14-slot Rack-Mountable PXI Chassis
* 14-slot 19-inch rack-mountable chassis
* Fully PXI and cPCI compliant
* Full PXI functionality in all slots
* Separate cooling fans for power supply and PXI slots
* Variable speed fans to minimize noise
* Temperature and PSU monitoring
Team Solutions' TE1014 is a 14 slot, 19†rack-mountable chassis, which fully
compies with the PXI and Compact PCI standards. All slots have full PXI functionality. Separate forced-air cooling is provided for the power supply and PXI slots. Fan noise is minimized by varying fan speed according to system temperature. Standard features include temperature and PSU monitoring with full software support. The expanded slot capability of the unit provides system integrators with a single-box solution, thus avoiding synchronization, integration and cost issues associated with multi-platform solutions. With a compact case size of 4U / 19â€, the TE1014 provides the small footprint required for today’s ATE and Data Acquisition applications.
Program / Software Information
Full software support for temperature and PSU monitoring. Software tool provided.
