NAKAMURA-TOME MODEL TMC 30 CNC TURNING CENTER*
Maximum Swing: 19.69"
Distance Between Centers: 21.65"
Spindle Speed: 4500 RPM
Through Spindle Hole Diameter: 3.15"
Turret: 10 Station
EQUIPPED WITH:
Fanuc 11T Control
10" 3-Jaws Chuck
Tailstock
20 HP AC Main Drive Spindle Motor
Chip Conveyor
Approximate Overall Dimensions: 160" L-R x 62" F-B x 72" H
Approximate Weight: 10,000 Lbs.
Serial Number: A35001 (New 1989)
P2 F.O.B. Elk Grove, IL - $ 19,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
