"20" Drill Press Operating Instructions and
This is a reproduction, not a photocopy, of an original Powermatic 20" Drill Press Operating Instructions and Parts list for Model # 1200. This manual covers drill press with serial numbers 1001 and up. It contains information on lubrication, adjustmens, maintenance, and controls as well as a complete parts list with exploded view diagrams.
Specifications.........................................2
General Setup........................................3
Operating Instructions......................4 & 5
Adjustments...........................................5
Lubrication.............................................5
Drill Speeds...........................................6
Parts Diagrams....................................7-9
Parts List.....................................10 & 11
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
