12" SURFACE GRINDER, Tos BHP320A AUTO IDF, 3X
12" SURFACE GRINDER, Tos BHP320A AUTO IDF, 3X
12" x 36" SIGMA TOS HYDRAULIC SURFACE GRINDER
** AUTOMATIC INCREMENTAL DOWNFEED **
MODEL: BPH-320A S/N: 177546 NEW: 1986
WIDTH & LENGTH GROUND ..................... 12" X 36"
HEIGHT OF WORK GROUND W/10" WHEEL .......... 13.75"
MAXIMUM LONGITUDINAL TRAVEL ................ 41.75"
LONGITUDINAL TABLE SPEED ................... UP TO 50' FPM
MAXIMUM CROSS TRAVEL ....................... 13.75"
AUTOCROSSFEED INCREMENT PER TABLE PASS ..... UP TO 3/16"
CONTINOUS CROSSFEED RATE FOR TRUING ........ 10" IPM
CONTINOUS CROSSFEED RATE FOR RAPID ......... 12' FPM
HANDWHEEL, HAS ADJUSTABLE DIAL GRADUATED
TO READ TO ................................. 0.0004"
VERTICAL TRAVEL OF SPINDLE .................. 15.75"
AUTO INCREMENTAL DOWNFEED FEED ...... 0.0002" TO .001"
POWER VERTICAL POSITIONING RATE ............. 20" IPM
HANDWHEEL HAS ADJUSTABLE DIAL GRADUATED
TO READ TO ................................ 0.0004"
APPROXIMATE MACHINE WEIGHT ................. 7,480 LBS
APPROXIMATE FLOOR SPACE .............. 120"L X 79"D X 85H"
AUTOMATIC INCREMENTAL DOWNFEED
HYDRAULIC LONGITUDINAL & CROSS FEEDS
AUTOMATIC ELECTRIC CROSSFEED REVERSAL OPTION
FINE FEED KNOB FOR CROSS FEED HANDWHEEL (.0001" GRADUATION)
10" DIAMETER x 1.25" WIDE x 3" BORE GRINDING WHEEL
12" X 36" FINE-DIVISION ELECTRO-MAGNETIC CHUCK
COOLANT TANK & PUMP w/GUARDING & PIPING
** EXCEPTIONAL CONDITION & APPEARANCE (ORIGINAL PAINT) **
** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE **
Machine Location: HARRISON, NJ
