MASTECH TRIPLE DC LINEAR POWER SUPPLY 30V 5A w/ Memory
For sale is a brand new lab-grade DC regulated power supply with advanced micro-processor control from Mastech, Model number HY3005M-3. This high quality power supply has three outputs: two outputs are continously adjustable at 0-30V DC and 0-5A, and the third output is fixed at 5V DC and 3A. What's more, the two outputs can be used either in independent, series or parallel mode, providing either two independent outputs, or one output with twice the voltage or twice the current output, up to 60V or 10A. The unit comes with 4 bright LED displays, providing accurate and clearly visible readout for the voltage and current value. The digtial control and keypad entry allows easier adjustment and better control for set point, as well as better stability and accuracy for the output. This unit has toggle switch at the back that allows you to operate it in 110V AC or 220V AC. retails well over $400. Please email us with any questions, our hard-working staff will answer every email in no time!
Two level of control for both current and voltage outputs: coarse and fine for ease of use
* Dual adjustable outputs: 0-30V and 0-5A
* Advanced microprocessor control
* Keypad entry with memory and lock for controlling both current and voltage outputs
* Input voltage: 110V AC and 220V AC switchable
* Line regulation: CV <= 0.01% + 2 mV, CC <= 0.2% + 2 mA>
* Load Regulation: CV <= 0.01% + 3mV, CC <= 0.2% + 3 mA
* Ripple noise: CV <= 0.5 mV RMS, CC <= 3 mA RMS
* Protection: constant current and short-circuit protection
* LED reading accuracy: +/-1% for voltage and +/-2% for current
* Environment: 0-40C, relative humidity < 90%
