16" SURFACE GRINDER, Mark 1628 AUTO IDF, 3X A
16" SURFACE GRINDER, Mark 1628 AUTO IDF, 3X A
(MADE BY PROTH) (ALSO SOLD BY SHARP)
AUTO INCREMENTAL DOWNFEED CONTROL
ADDED TO MACHINE IN 2007 BY FACTORY
Maximum distance: table to spindle center: 23.6"
Table travel (cross x longitudinal): 18" x 33.6"
Longitudinal hydraulic table feed: 6.6 - 82 FPM
Intermittent cross feed (in. feed): 0.004 - 0.4 IPM
Number of graduations on dial: 200
Number of graduations on dial: 500
Wheel size (OD x W x ID): 14 x 1.5" x 5"
Packing crate dimensions (W x D x H): 8' x 6' x 7'
"AMW" Model CD-26 Programmable Microprocessor
Auto IDF Control w/CRT Display
16" x 27- 1/2"" Fine-Division Electro-Magnetic Chuck
Wheel balancing stand & Puller
Push-Button Rapid Up & Down Wheelhead
All (3) handwheels @ operator's hip level
Machine is presently wired for 3/60/220 volts
** MACHINE WAS MFR'D IN 2001 **
Machine Location: HARRISON, NJ
