2 HUGE 16 POUND INDUSTRIAL GRADE
FlUID REACTOR MAGNETIC SCALE CONTROL UNITS
These are designed to be used in clusters on large pipes from 4" to 60" (formula is 1 per .75 x pipe diameter for non-magnetic pipe, and 1 x pipe diameter for magnetic pipe).
Applications:HVAC, cooling towers, heat exchangers, chemical plants, boilers, oil wells flow lines, oil pumping stations, oil side heat exchangers, salt water.
Effective Gauss: 2000+ actual value of gauss that is working for treatment, Effective gauss equals meter reading x tangent angle between gauss direction and fluid direction.
Unit Dimensions: 71/2 x 31/2 x 5 inches
How Magnetohydrodynamic (MHD) Technology Works
MHD technology also know as magnetic fluid dynamics or magnetic fluid conditioning, reverses the laws of physics that cause minerals, such as calcium carbonate, to precipitate out of solution, cluster, and form hard scale through crystallization.
1. Molecules suspended in fluids tend to cluster.
2. A fluid traveling through a pipe or line carries these molecules and clusters.
3. Larger clusters trap molecules.
4. These larger clusters tend to slow in speed and gravitate toward the side of the pipe or line forming unwanted deposits which restrict the flow of the fluid.
5. Immediately, as the flow of the fluid brings clusters of molecules in contact with the powerful magnetic circuitry of the power unit, clusters are broken apart with a single instantaneous jolt.
6. Free of clusters of molecules, the fluid proceeds through the pipe or line with the chemical characteristics of the fluid intact.
7. The impact of the magnetic circuitry is retained or "remembered" by the suspended molecules, preventing additional clustering as well as scale from forming.
No system is too old. When pre-existing scale with the corresponding correct magnetic property comes into contact with the flow of the treated fluid, it can become resuspended and gradually removed.
While MHD influence does not change the chemistry of the water, it has an effect on the carbonates that are allowed to precipitate out of solution. Scale forming carbonates are predominately a combination of two crystalline forms, aragonite and calcite. Calcite is the principle ingredient in hard scale and not only has a much more dense crystalline structure than aragonite but is also made up of adherent molecules. Aragonite's molecules are non-adherent molecules. An independent laboratory study reported by the American Society of Corrosion Engineers states 'Water that was not treated by magnetics precipitates a ratio of calcite to aragonite of 80% to 20% while the ratio measured in magnetically treated water was almost the opposite, 30% to 70%. The higher percentage of aragonite causes the formation of a soft scale or sludge that's more easily cleaned or carried through the system without creating a hard scale buildup on the lowest velocity area of the delivery system i.e., the walls of the pipe."
* 99% effective over 99 years
* Enhances Reagent Diffusion
The table above shows typical loss of efficiency proportional to varying thickness of scale. It clearly illustrates the importance of maintaining your HVAC equipment. You could be losing a huge percentage of your energy costs due to scale buildup in boilers, water heaters, and heat exchangers.
Scientific Documentation of the Effectiveness of MHD Technology
MHD technology has gained wide acceptance by engineers in both the public and private sectors. The development and introduction of higher power, and rare earth element magnets, has widened the scope of applications, flow rates, and the pipe diameters that can be dealt with effectively.
Many studies have been performed proving the effectiveness of MHD technology.
"We can now show that the influence of magnetic fields on precipitation extends beyond simple descaling: it can prevent scale from forming."
US Department of Energy / Tulane University and Purdue University
"Magnetic water conditioners, a non-chemical method of treating water, are operating extensively throughout the world today with tremendous economic effect."
"Findings indicate that magnetic water treatment is extremely successful in private sector boiler and cooling tower water treatment applications. Scale is eliminated and corrosion rates are significantly reduced."
The US Department of Defense Air Force Office of Scientific Research Report; Magnetic Treatment of Water
"There am many basic areas where the utilization of this method has great practical merit as the elimination of scale."
The US Department of Energy in their Federal Technology Alert; Non-Chemical Technologies for Scale and Hardness Control
"Two experiences have been common. First, users have noted a dramatic reduction in scale formation to the point where the need for chemical scale control is eliminated. Second, the prior buildup of scale on heat exchanger surfaces has been removed over time."
Advanced Research Projects Agency
"Magnetically treated water, also called "magnetic water' is widely used in boilers for all purposes (everyday hot water requirement, power, heating systems, river and oceangoing vessels, etc.) and to increase the life of pipes in the oil, coal and mining industries, since it sharply reduces corrosion and the deposit of organic and inorganic compounds (such as paraffin) in pipes."
Continuing research shows that we have yet to discover all of the benefits and applications of MHD technology. The most recent findings point to the ability of MHD technology to enhance reagent diffusion and control pH levels and corrosion.
"accelerated chlorine diffusion in hard water so effectively that 65% less chlorine would be required to control macrofouling and biofilm buildup in their water service systems. Sediment buildup was also controlled and heat transfer rates were maintained at optimum efficiency. Also, pH levels were dramatically stabilized."
Magnetic Water Treatment in Lieu of Chemicals, Florestano et al
"Laboratory studies report that magnetic treatment reduces oxygen saturation levels in water which correspondingly reduces corrosion."
I now carry a complete line of MHD magnetohydrodynamic water, fuel, fluid and gas treatment devices. These were developed and maufactured in the USA by an engineer who is one of Godfathers of this industry. MHD technology is based on the theory of Diamanetics which cause particles such as salts that cluster and form deposits in fluid systems to stay in suspension in the fluid and not parcipiate out causing scale and other unwanted formations.These devices are in use worldwide in homes and industry. For the treatment of everything from drinking water to oil rigs.
