Lot 4000 Samsung Flash Memory 256Mb K9F5608U0C-PCB0 NEW
Available for purchase is four thousand (4000) Samsung 256MB NAND Flash Memory Modules / Chips. The product number for this memory is # K9F5608U0C-PCB0.
This memory is 256M bit with spare 8M bit capacity. The I/O pins serve as the ports for address and data input/output as well as command input. The on-chip write control automates all program and erase functions including pulse repetition, where required, and internal verification and margining of data.
* Voltage supply: 2.7 ~ 3.6 V
* Memory Cell Array: X8 device : (32M + 1024K)bit x 8 bit
* Data Register- X8 device: (512 + 16) bit x 8 bit
* Page Program- X8 device : (512 + 16) Byte
* Block Erase- X8 device: (16K + 512) Byte
* Page Size- X8 device: (512 + 16)Byte
* Serial Page Access : 50ns(Min.)
* Fast Write Cycle Time: Program time 200s (Typ.); Block Erase Time 2ms (Typ.)
* Command/Address/Data Multiplexed I/O Port
* Program/Erase Lockout During Power Transitions
* Reliable CMOS Floating-Gate Technology
* Endurance : 100K Program/Erase Cycles
* Command Register Operation
* Unique ID for Copyright Protection
* Power-On Auto-Read Operation
* Package: 48 - Pin TSOP I (12 x 20 / 0.5 mm pitch)- Pb-free Package
Even write-intensive systems can take advantage of the K9F5608U0C's extended reliability of 100K program / erase cycles by providing ECC(Error Correcting Code) with real time mapping-out algorithm.
The K9F5608U0C memory module is an optimum solution for large nonvolatile storage applications such as solid state file storage and other portable applications requiring non-volatility.
This lot of memory is brand new.
