98" PLATE ROLL, Hendley 4-G Air Drop End
98" PLATE ROLL, Hendley 4-G Air Drop End
8' x 1/4" HENDLEY & WHITTEMORE CO.
Initial Pinch-Type Bending Roll
Model 4-G, S/N 15048 (New 1957)
Flush floor mount, no pit required
Pneumatically actuated drop end
Dual handwheels for simultaneous manual adjustment
of lower front pinch roll from each end of the roll
Motorized adjustment of rear forming roll
7-1/2 H.P. 3/60/220-440 volt V-belt driven roll drive
motor with Forward/Reverse/Stop push button controls
Machine is wired for 220 volt operation.
Machine is mounted on a structural I-beam.
Approximate Weight: 5,600 Lbs.
Approximate Floor Space Required: 170" L-R x 60" F-B
