13" ENGINE LATHE, Sharp 1340F 16 Speed Headst
13" ENGINE LATHE, Sharp 1340F 16 Speed Headst
- jog button for easy engagement of gears & inching spindle
- larger compound, tailstock & apron than competitive models
allows heavier cutting with less vibration
- 16 speed ("F" models), all geared headstock housed inside a
- quick-change gearbox offers wide range of threads
Spindle nose type: D1-4 Camlock
Spindle Speeds: 45 - 1,800 RPM (16 speeds)
Longitudinal feeds - inch per rev (40): 0.0012 - .0294"
Cross feeds - in/rev (40): 0.0003 - 0.01"
Inch threads (40): 4 - 112 TPI
Metric threads (22): 0.45 - 7.5mm
Leadscrew pitch, diameter: 8 TPI, 7/8"
Compound width x length: 3-1/8 x 8"
Quill travel (graduated): 4-1/2"
SPECIFY: 220V or 440V, 3 Ph, 60 Hz
Net weight (approximately): 1,540 lbs
coolant system, 4-way toolpost, steady rest, thread dial, foot
brake, center sleeve (MT #5 x #3), dead centers (MT #3) tool kit,
removable gap block & splash guard.
OPTIONAL EQUIPMENT (Call for prices)
Follow rest, digital readout system, taper attachment, micrometer
carriage stop, 3-jaw scroll chuck (8"), 4-jaw chuck (8"), face plate
(12"), single toolpost, live center (MT #3), & drill chuck.
Machine Location: HARRISON, NJ
