Welds material from 22 gauge to 1/2 in thick mild steel in a single pass.
* Miller's patent-pending Active Arc Stabilizerâ„¢ provides excellent starts proven superior to the competition!
* Adjustable run-in control is individually settable for both MIG and spool guns. Set at the front panel, this easily accessible feature allows the user to optimize starts to their application.
* Self-calibrating digital meters allow presetting of voltage and wire feed speed. With spool gun, wire speed meter displays setting - a feature not available on competitive units.
* Easy-to-use Digital Operator Interface and attached parameter chart makes it simple to set weld parameters.
* Convenient built-in gun and cable holder and consumable compartment.
*1 Second Tip Saver - Arc shuts off if tip is shorted to work surface for more than 1 second.
*2 Minute Wire Saver - Wire drive is shut off if arc is not detected 2 minutes after trigger is pressed.
* Industrial, dual-gear-driven, aluminum drive system features no-tool, quick-change reversible drive rolls and an easy-to-set, scaled tension knob.
* Fan-On-Demandâ„¢ cooling system only operates when needed reducing power consumption.
* M-25 MIG Gun features durable one-piece handle, unicable outer jacket, trigger rated for one million cycles, and steel spring coils protecting cable ends.
* Light Industrial Applications
* 200 Amps at 28 VDC, 60% duty cycle
* 250 Amps at 28 VDC, 40% duty cycle
* Power cord and plug (200/230 V model only)
* 12 ft (3.7 m), 200 amp M-25 MIG Gun for .030/.035in wire
* Argon mix regulator/flow gauge and hose
* Factory-installed Running Gear/Cylinder Rack
* .030/.035 in reversible drive rolls
* Set-up and operation video
