Hi-resolution, reproduction grade scans of the INSTRUCTION (SERVICE & OPERATING) MANUALS (2 volume set) with options, for the PG 506 CALIBRATION GENERATOR, Plug-in for the popular TM500 series of modular test equipment, Scanned from an original Tektronix manual not a US Government TM Manual
* Covers serial numbers B010100 through B039999
Covers serial numbers B040000 and above
* Calibration & Adjustment
* Electrical & Mechanical Parts lists
* Schematics & Circuit Board Part Locators views
* Electronic page numbers = original manual page numbers (1-1,1-2, etc)
* 600dpi schematic scans for detail printing
* FULL SIZE, A3, 11x17, scans of foldouts and Schematics
* Fully printable in Hi resolution
* Schematics you can read !
SAMPLES AVAILABLE FORM THE ACTUAL MANUAL ON SALE , EMAIL US FOR DETAILS.
