Liberty Machinery Company-You are looking at a Cincinnati Landis, No.Viking 200, Maximum Work Diameter 2.5", 20 HP, OA 9600 CNC, Coolant-Serial No. HV 35025Condition - Used
-SPECIFICATION: Grinding Wheel Diameter - Maximum 16" (405 mm)
Grinding Wheel Hole Size 8" (203 mm)
Regulating Wheel Diameter - Maximum 12" (305 mm)
Regulating Wheel Hole Size 7" (178 mm)
Work Diameter 0.05" - 2.5" (1 - 60 mm)
Grinding Wheel Width 8" (205 mm)
Regulating Wheel Width 10" (255 mm)
Main Drive Horsepower 20 HP (15 kW)
Surface Speed 8,500 SFPM (45 m/Sec)
Optional 18,000 SFPM (90 m/Sec)
Regulating Wheel Speeds 10 - 600 RPM
Approximate Weight 20,000 Lbs. (9072 kg)
Cincinnati Milacron OA9600 "Open Control System" CNC Control
United Air Specialists Model VCC-1500 Mist Collector
Barnes Combination Magnetic Drum/Paper Filtration System
Part Tolerances to 0.000 0006" (0.15 micron)
No Cams to Make, Store or Maintain
Fast Setup, Especially on Repeat Work
Program and Edit while in Cycle
Standard Push Button Operation
Consistent Processing Parameters
Management Reporting Capability
