"Ex-Cell-O Ram Turret Milling Machine Style 602
Operation and Instruction Manual"
This is a reproduction, not a photocopy, of an original Ex-Cell-O Ram Turret Milling Machine Style "602" Operation and Instruction Manual. This manual contains information on lubrication, adjustmens, maintenance, and controls as well as a complete parts list with exploded view diagrams.
Machine Specifications.............................................................2
Installation................................................................................3
Operating Instructions...........................................................4-5
Adjusting Gibs.........................................................................6
Aligning Head..........................................................................6
Eliminator Nuts........................................................................6
Ordering..................................................................................7
Head Temperature...................................................................7
Spindle Brake & Lock.............................................................7
Spindle Belt Replacement.........................................................7
Replacing Quill Return Spring...................................................7
Replacing Quill Guard..............................................................8
Replacing R-8 Drive Key.........................................................8
Table Power Feed...................................................................8
Spindle Bearings....................................................................21
Lubrication..............................................................................9
Manual System.................................................................10-11
One Shot System.............................................................12-13
Automatic System............................................................12-13
Head Drive......................................................................14-16
Head Body Assembly.......................................................16-20
Spindle Assembly...................................................................21
Dovetail Ram Assembly....................................................22-23
51/2 Riser Assembly..............................................................23
Machine Assembly...........................................................24-27
Table Power Feed Assembly............................................28-29
Right Angle Attachment Assembly.....................................30-31
Horizontal Mill Attachment Assembly................................30-31
Anti-Backlash Nut Assembly..................................................32
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions email me or send me a picture first. I
