Tek 7S12 service/op manual - with no advertising added


Poster: 231404015@iowa-industrial.com

Tek 7S12 service/op manual - with no advertising added

Tektronix 7S12 Plug In Service and Operating Manual in both Very High and in Standard Resolution PDFs on CD
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
These PDFs include operations information, maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams. These are scans of the manufacturer's commercial manual, NO REDUNDANT MILITARY MATERIAL is used to "beef up" a "volume count".
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 600dpi grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 256 colors 600dpi
Please be aware that our scans are actually made at the specified resolution, so are often (as in this case) much larger than so-called "competitors" falsified offerings. The very high res (600/300 dpi) scan of this is 482MB in size.
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. In this case, it comes in at 21MB.
"AND IF THAT'S NOT ENOUGH FOR YOU":
As "bonus" material, includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF as well as a useful text-searchable scan of the 1990 Tektronix Catalog, featuring almost 3,000 Tektronix Products. These bonuses are all provided at no additional charge!
