19"X72" cincinnati hydrashift lathe, 37-1470 rpm(18608)


Poster: 1018516285@iowa-industrial.com

19"X72" cincinnati hydrashift lathe, 37-1470 rpm(18608)

19" x 72" cc, CINCINNATI, Hydrashift, 37-1470 RPM, Coolant, Clean Our stock number: 18608 Cincinnati Hydrashift Lathe MODEL..................................19" Hydrashift
Cincinnati Hydrashift Lathe SERIAL NUMBER..........................HT522G
Cincinnati Hydrashift Lathe GENERAL SPECIFICATIONS
Swing Over Bed.........................19"
Distance Between Centers...............72"
Spindle Speeds.........................(12) 37 To 1470RPM
Spindle Nose...........................L-1
Hole Through Spindle...................1-3/4"
Number Of Threads & Feed Changes.......(48)
Range Of Threads.......................1-1/2" To 92"
Range Of Feeds........................ .0019 To .1215 IPR
Cross Slide Travel.....................12"
Top Slide Travel.......................3-1/4"
Tailstock Spindle Travel...............5"
Cincinnati Hydrashift Lathe EQUIPPED WITH
5 HP Motor, 1750 RPM 220/440/60/3
Chip Pan *does not do metric threads.
Cincinnati Hydrashift Lathe Approximate Weight....................3700 Lbs.
All items are sold SPECIFICATIONS SUBJECT TO VERIFICATIONS.
All items are offered locally and could be sold previous to end of store listing.
**********PLEASE READ BELOW**********
**Skidding, crating, palletizing and/or packaging of any item are an additional cost and will be added to the items final purchase price. Skidding fees range from a minimum of $50.00 +. **
**We will load on a flat bed, open truck or trailer free of charge. **
**Skids shown in pictures are not included with the item. **
If you want to purchase an item and have circumstances requiring the item to be picked up at a later date, please inform us before the item is purchased.
We thank you in advance for your interest in this item. Please feel free to call or e-mail us with any questions or other machinery requirements. (***)-745-6008
