18" ENGINE LATHE, Birmingham NDL-1840 Special
18" ENGINE LATHE, Birmingham NDL-1840 Special
New "Birmingham" Precision High Speed Engine Lathe
Model: NDL-1840 w/Removable Gap Block
Note: the photo shows the 20" x 60" centers model
Attachment (including installation)
Full length cast iron base with easy exit chip removal
Hardened and ground gears, shafts and bedways
D1-8 Camlock spindle with 3-1/4" bore
12 spindle speeds, 16 - 1,600 RPM
Full length splash guard and foot brake
Oil bath lubricated headstock and gearbox for smooth, quiet operation
One-shot lube system for apron and bedways
Swing over cross slide: 10-1/2"
Spindle nose type (Camlock): D1-8
Spindle speed range: 16 - 1,600 RPM
Threads per inch (No.) range (TPI): (44) 2 - 56
Metric threads (No.) range (mm): (24) 0.5 - 14
Module threads (No.) range (mm): (24) 2 - 56
Diametral threads (No.) range (DP): (44) 0.5 - 14
Long. feeds (No.) range (in/rev): (18) 0.002 - 0.032
Cross feeds (No.) range (in/rev): (17) 0.0007 - 0.0095
Leadscrew diameter (in): 1-3/8"
Main drive: 7-1/2 hp, 220/440V 3 ph
Maximum workpiece weight: 880 lbs.
10" 3 Jaw Chuck with top reversible jaws
Steady rest capacity 3-1/8" - 7-7/8"
Follow rest capacity 3/4" - 3-9/16"
Optional Equipment (call for pricing):
12" Larger steady rest with roller jaws
5C Hand lever type collet closer "JFK" USA
DRO - Newall, Acu-Rite or Uniq
Machine Location: HARRISON, NJ
