275 East 131st Street - Cleveland, Ohio 44108 U.S.A.
AMPAK 3340 ROTOMATIC DIE CUTTER
Machine is Reconditioned in Good Working Order.
Automatic pneumatic chase with safety limit switches.
Cuts product on forward stroke only – won’t double cut.
Dual push-button safety start switches.
6†diameter rigid steel cutting rolls with heave duty bearings.
Left and right side pressure roller height adjusters with lock downs.
MACHINE DIMENSIONS: 68†long x 50†wide x 68†tall ( with chase open ).
VOLTAGE: 220 VOLTS AC / 3 PHASE / 6 AMP.
AIR PRESSURE: 1 Cu. Ft. / CYCLE @ 80 P.S.I.
MINIMUM RULE: 1.125†/ 3 point.
TYPICAL RULE MAXIMUM: ( including hanger holes / punches ) – 24 contact points and
