21"/28" x 80" cc, KINGSTON, Gap, Inch/mm, 3" Hole, 25-1500 RPM, 10 HP, 1986 Our stock number: 20419
SERIAL NUMBER: 10750418A Year: 1986
Swing Over Cross-Slide: 13-1/8"
Spindle Speeds: (12) 25 to 1500 RPM
Threads, U.S. Standard: 4 to 56 t.p.i.
Metric Modules: 0.5 to 7.0 mod.
Diametral Pitches: 4 to 28 D.P.
Longitudinal Feeds: .0024" to .037"
Lead Screw, Diameter: 1-5/16" or 4 TPI
Tailstock Spindle Travel: 5-7/8"
Tailstock Spindle Diameter: 2-9/16"
15" 4-Jaw Chuck, 12" 3-Jaw Chuck
All items are sold SPECIFICATIONS SUBJECT TO VERIFICATIONS.
All items are offered locally and could be sold previous to end of store listing.
**Skids shown in pictures are not included with the item. **
**All items requiring a skid will have an additional skidding fee added to the items final purchase price. Skidding fees range from a minimum of $50.00 +. **
**We will load on a flat bed, open truck or trailer free of charge.**
