â— Power supply: 9V battery ( ANSI / NFDA 1604A or IEC6LR619V alkaline)
â— Max. permitted voltage: 30v (between any two terminals or between any terminal and earth ground)
◠Operating temperature: 0℃ to 50℃
◠Operating relative humidity: ≤80﹪RH
◠Storage temperature: ≤-10℃ to 55℃
◠Size: 200×100×40 mm(with holster)
â— Accessory: operation instruction, a set of CF-36 industrial test lead (with alligator clips)
â— Option: AC power-supply adapter (VCPS) and a set of CF-31-A industrial test lead (with probe clips)
â— Safety: Certified as compliant to IEC1010 provisions (Safety Standard issued by International Electro technical Commission)
Output Function & Specification (applicable to temperature range from 18 to 28 ℃ ,within one year after calibration).
Input function & Specification (applicable to temperature range from 18 to 28 ℃,within one year after calibration).
Note 1: The accuracy does not include the error of internal temperature compensation caused by a sensor. The range of the internal temperature compensation sensor is from -10 to 50 ℃ with its compensating error up to 0.5℃.
Note 2: temperature coefficient: ±0.005% of range per℃ for the temperature ranges from 0 to 18℃ and from 28 to 50℃.
All our Calibrators are provided one year warrantee by us from the date you make a purchase. An replacement or repairment will be provided by us for free when a faulty is developed within the warrantee.
