Etc-211000 ranco microprocessor temperature control


Poster: 1522430102@iowa-industrial.com

Etc-211000 ranco microprocessor temperature control

RANCO ETC-211000-00 Electronic Temperature Control
Unlike many electronic controls, the ETC is simple to install and set up. One finger is all you need to program it. The standard digital display and keypad allow the user to adjust the temperature settings with 1° resolution. Setpoint temperature, differential and mode of operation (heating or cooling) can all be selected using the keypad and display. When not in the programming mode, the display gives a constant readout of the sensor temperature. Annunciators on the liquid crystal display also indicate when the relay is energized. The ETC is capable of remote temperature sensing up to 400 feet away from the control when using standard 22 gauge sensor wire. Every ETC model is equipped with diagnostic programs that check for hardware, software or system problems and display different error codes to indicate where the trouble is. The ETC also has a keypad lockout switch to prevent tampering with the control settings by unauthorized personnel. The switch, which is located inside the enclosure, can be used to disable the keypad function
Type Electronic Temperature Control
Characteristics Hardware, Software or System Problems and Displays Different Error Codes for Easy Troubleshooting, EPROM Memory Retains Control Settings During Power Outage, Replaces Most Electromechanical and Electronic Temperature Controls
Application For Selectable Heating/Cooling Modes for Use in Hundreds of Commercial HVAC/R Applications, Keypad Lockout Switch Prevents Tampering
Cooling Full Load @ 120V 16A (NO), 5.8A (NC)
CLICK HERE FOR ADDITIONAL INFORMATION
