6 MULTI-SPINDLE DRILL, Clausing 2237 & 1657 (
6 MULTI-SPINDLE DRILL, Clausing 2237 & 1657 (
CLAUSING SIX SPINDLE DRILL PRESS
MODELS:(1)1657 & (5)2237, S/N's: 126493,105370,2,3 & 4 NEW: 1970'S
OVERALL SIZE OF TABLE ................ 29-1/2" X 125-1/2"
TABLE WORKING SURFACE ................ 24" X 120"
APPROXIMATE WEIGHT ................... 4500 LBS
ONE 15" STEP-PULLEY HEAD MODEL: 1657
CAST IRON ........................ 5/8"
MILD STEEL ....................... 1/2"
DRILL TO CENTER OF CIRCLE ............ 15"
SPINDLE TAPER ........................ #2 MORSE
SPINDLE TRAVEL ....................... 4-3/4"
SPINDLE DIAMETER ..................... 2"
SPINDLE SPEEDS(5) .................... 260 - 3600 RPM
COLUMN DIAMETER & THICKNESS .......... 3"DIA x 3/16"WALL
FIVE 20" STEP-PULLEY HEAD MODEL: 2237
CAST IRON ........................ 1-1/8"
STEEL ............................ 7/8"
DRILL TO CENTER OF CIRCLE ............ 20"
SPINDLE TAPER ........................ #3MT
SPINDLE TRAVEL ....................... 6-1/2"
SPINDLE DIAMETER ..................... 2-1/2"
SPINDLE SPEEDS(10) ................... 150 - 2000 RPM
POWER DOWN FEEDS(4) .................. .004, .006, .009 & .012
COLUMN DIAMETER & THICKNESS .......... 4"DIA x 1/2"WALL
- 29-1/2" X 125-1/2" LARGE PRODUCTION TABLE WITH TROUGH
- HEAD RAISING & LOWERING RACK MECHANISMS
- (1) MODEL: 1657 STEP-PULLEY 3/4 HORSE POWER HEAD
- (5) MODEL: 2237 STEP-PULLEY 1-1/2 HORSE POWER HEADS
- THE FIVE 20" DRILL HEADS COME EQUIPPED WITH POWER DOWN FEED
CLAUSING MODEL:2215 GEAR DRIVEN POWER FEED
INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
Machine Location: HARRISON, NJ
